Standard Enclosures

Wall/Floor Mounting Metal Enclosure can be installed in different electrical Control systems, Machinery transmission, Pump, and etc. Whether you design your enclosure or make use of our simple standard design, you can always trust Sunshine for the quality and service you are looking for.


  1. Made out of high quality Electro galvanized steel
    from 0.9mm thickness (up to 3mm GI)
  2. Detachable Mounting plate for component installation
    from 1.4mm GI onwards
  3. Finished with Powder coating
    Body and Door in RAL 7032, MP in RAL 2000
  4. Up to IP65
  5. Triangular Lock to ensures uniform locking over the entire length
  6. Removable Gland plate at the Bottom with gasket
  7. Available in Double door construction for width from 1200mm
  8. Wall mounting provision up to 1000mm height

Technical Data

Material – GI
Thickness – From 0.9 mm – 3 mm
Options – Internal Door, Glass Window, Canopy, Cut outs, Louvers, Paint (on request).
